Description
ENGINE hpe single cylinder, 4 stroke, 4 valve, electronic injection
BORE X STROKE 75 mm x 70,1 mm
DISPLACEMENT 310 cc
MAX POWER 18,4 kW (25 HP) @ 6,500 rpm
MAX TORQUE 28,9 Nm @ 5,250 rpm
FUEL SYSTEM New Electronic Injection PFI (Port Fuel Injection)
STARTER Electric
TRANSMISSION CVT with torque server
CLUTCH Automatic dry centrifugal clutch with vibration dampers
COOLING Liquid
LOAD BEARING STRUCTURE Sheet steel body with welded reinforcements
FRONT SUSPENSION Single-arm with coil spring and single shock absorber
REAR SUSPENSION Double hydraulic shock absorber with preload adjustable on 4
positions
CONSUMPTION (KM/L) 31,2 km/l
EMISSIONS (CO2) 74 g/km
EMISSIONS APPROVAL Euro 5 +
FRONT WHEEL Tubeless 120/70 – 12”
REAR WHEEL Tubeless 130/70 – 12”
FRONT BRAKE Stainless steel disc, Ø 220 mm with hydraulic control –
ABS/ASR
REAR BRAKE Stainless steel disc, Ø 220 mm with hydraulic control –
ABS/ASR
LENGTH/WIDTH/WHEELBASE 1,975 / 775 / 1,375 mm
SEAT HEIGHT 790 mm
FUEL TANK CAPACITY 8,5 liters (including 2 liters reserve)
